An Analysis of Rotor-Induced Vibration on Winged eVTOL Aircraft

Alexander Stillman, Etana Ferede, Farhan Gandhi, North Carolina State University

https://doi.org/10.4050/F-0081-2025-0351

Abstract:
This study investigates the vibratory loads and stresses on an electric vertical takeoff and landing (eVTOL) aircraft featuring internal batteries and four rotors mounted on underwing booms on a semi-span wing. During low-speed forward flight (20 kts), the rotor excitation frequency is closest to the wing's second torsional mode, resulting in dominant vibratory torsional moments at the wing root. A full rotor phasing sweep reveals that relative phasing has a critical effect on peak-to-peak (P2P) wing root loads and stress levels. Selected phasing configurations are shown to reduce maximum wing root P2P principal and shear stress resultants by over 70% and 60%, respectively, compared to their mean peak-to-peak values over the phase sweep. Sensitivity analysis further indicates that increasing rotor speed shifts the dominant vibratory response from torsional to flapwise bending modes.
