Abstract:
This paper describes the methodology, involving testing and simulation activities, to assess malfunction conditions of complex systems installed on fly-by-wire vehicles, including the evaluation of their effects. This paper provides also a description about how the system malfunction tests are designed, driven by input requirements and systems capability and behavior. With respect to prior publications, this paper includes some practical test examples, based on systems monitoring, logics and alerting functions. The case study described here comes from a portion of multiple laboratory certification tests done for AW609 Tiltrotor, focused on Avionics System malfunctions. These tests and simulations are a valuable Means of Compliance with respect to applicable airworthiness rules, and a suitable means to verify the design safety requirements. Three relevant examples are presented, grouped by input requirement and safety conditions. The effect of such malfunctions is evaluated, with respect to the Avionics System output produced to keep adequate flightcrew awareness about the vehicle status.
