Abstract:
The Main Gearbox of a helicopter is a crucial component that delivers the desired performance and ensures the highest possible level of safety of the aircraft; it includes several gears and bearings, which require to be continuously lubricated by a pressurized oil flow. Undesired circumstances may cause the oil to leak from the main circuit, hence reducing its pressure and consequently the oil flow rate targeted towards the rotating components; this modifies their friction coefficient, and subsequently leads to an overheating of the parts with the risk of degenerating in a catastrophic failure. During the design of a helicopter drive system, engineers need to take proper precautions and make sure that the MGB is fully equipped with the proper features to cope with a loss of lubrication event; specifically, the drive system is supposed to be able to run at least 30 minutes after the oil pressure drops to zero. A lot of effort has been put over the years at Leonardo Helicopters to find robust solutions to attain the longest performance of the drive system in no-oil conditions: the most important result is the certification of the AW189 for a 50-minutes “run dry” capability. Nevertheless, the dynamic environment typical of the rotorcraft industry pushes towards continuous innovation, and in the last few years the Transmissions Systems Design department of LH has been asked to investigate suitable ways to further augment the no-oil capabilities of the MGB: the main steps followed and entailed results are presented in this paper. The first part of the manuscript discusses the “state of the art” auxiliary lubrication system, currently flying on the AW189 drive system. The second part tackles the approach adopted to meet the novel requirements, unveiling both the methodology and the final design choice: the latter includes a metering element, able to tune the oil flow rate headed towards the component deemed the most critical in order to satisfy the requirement of longer no-oil performance. Numerical and experimental tools are exploited as complementary tools to properly crystallize the obtained results and corroborate the solution.
