Abstract:
Inspecting the interiors of tanks and ships for defects involves accessing confined and elevated spaces. This can be difficult and hazardous for a person. Ducted aerial vehicles that can hover close to the object of interest can achieve this in a safer and more efficient manner. Such a vehicle is desired to be compact, to have a high hover endurance and to be protected from impact. This paper describes a design concept comprising ducted coaxial counter-rotating rotors with a compact swashplate mechanism for cyclic pitch input to the lower rotor. An experimental setup was used to investigate the effect of the duct. A numerical Blade Element Momentum Theory model was developed and validated to inform rotor selection. A prototype was designed and built with a hover thrust of 9.17 N, outer diameter of 350 mm, and height 173 mm. The duct provided a thrust benefit of 32% for this configuration for a given power. The prototype achieved stable controlled flight in hover and in passing near walls and surrounding obstacles. Some oscillations in attitude were seen in flight. Future work includes improving the control algorithm of the vehicle.
