Abstract:
This paper discusses the development of a flight dynamics model (or digital twin) of a compact and re-configurable coaxial-propeller-based micro air vehicle (MAV) in hover, edgewise, and maneuvering flight using a hybrid physics-based plus data-driven approach. The MAV has a mass of 366 grams (0.81 lb), and features a 52 mm (2.05 in) diameter cylindrical fuselage, foldable propellers, and a two-axis gimbal thrust vectoring mechanism for pitch and roll control. The aircraft has been successfully launched from a pneumatic cannon and has achieved stable and controlled flight. A physics-based flight dynamics model of this novel MAV has been developed using Rotorcraft Comprehensive Analysis System (RCAS). RCAS is able to predict the translational dynamics near hover reasonably well; however, the accuracy decreases for rotational dynamics in edgewise flight resulting in significant differences between predicted dynamics and flight test data, known as residual dynamics. The current hybrid model utilizes the residual dynamics via a data-driven approach to correct the physics-based model. Using the measured vehicle states and control inputs, a deep neural network (DNNs) was trained to learn the residual forces and torques. The resulting hybrid model reduced prediction errors by 55% on average compared to the RCAS model based on pure physics.
