Abstract:
This study presents computational analyses of coaxial rotor hub flows and validation against experimental data obtained from the fifth Rotor Hub Flow Prediction Workshop. Experiments were conducted in a 12-inch diameter water tunnel at Pennsylvania State Applied Research Laboratory, employing tomographic particle-image velocimetry (Tomo-PIV) and precise hub drag measurements. Three CFD codes (UMD Mercury, CREATETM-AV Helios, and OVERFLOW) utilizing hybrid Reynolds-Averaged Navier-Stokes (RANS) / Large Eddy Simulation (LES) modeling based on Spalart–Allmaras turbulence model, were applied to replicate and analyze hub flows. Counter-rotating coaxial rotor hubs under free-air condition was simulated as the simplest case and the hub drags are compared between the three CFD codes. The full water tunnel configuration, consisting of two hubs, a fairing, and shafts, was also simulated and compared to experimental results, with a focus on hub drag, wake velocity fields, and turbulence quantities. Results demonstrated that the computational frameworks effectively captured key flow physics, although some discrepancies in drag harmonics, wake velocity and turbulence intensity magnitudes were observed. Additionally, the study highlighted the impact of rotor hub geometry and installation of sail-fairing on drag and wake structures. These findings contribute to improve computational predictions, essential for designing high-speed rotor hub configurations.
