Abstract:
This paper investigates the relationship between broadband noise behavior and helical wake structure in coaxial corotating rotors. Experimental measurements were conducted across variations in collective pitch (9.4°, 12.5°, and 15.0°) and rotor speeds (1500–4500 RPM). The inflow ratio (λ) was shown to govern the slope of broadband noise trends mapped in phase offset versus separation distance space, with experimental and theoretical λ values agreeing within 1%. Tip vortex core growth was estimated using the Ramasamy–Leishman model and normalized by the blade tip chord, reflecting the location of tip vortex formation. Across collective pitch variations, initial vortex core radii ranged between 7.5% and 9.1% and across rotor speeds, it ranged between 7.5% to 8.5% of the blade tip chord. When broadband noise trends became less coherent across phase offset angles, the corresponding vortex core radii were observed to approach or exceed 10% of the tip chord. At 4500 and 3500 RPM, vortex cores radii remained near or slightly above 10% at diffusion and depletion of broadband noise coherence. At 1500 RPM, initial vortex core radius is significantly beyond 10% of blade tip chord, leading to early diffusion, loss of organized wake structures, and broadband noise saturation across all phase offsets. If an inboard chord length were used instead for normalization, the specific normalized values would differ, but the overall trends in vortex diffusion and broadband noise coherence would remain similar. These results define a practical RPM threshold below which coherent wake structures and slope-based inflow prediction are no longer valid. Overall, the findings offer a framework for anticipating wake breakdown and broadband noise saturation, providing guidance for rotor design and operation to preserve low-noise performance.
