Abstract:
The paper presents a general framework for building an aeromechanic model in FLIGHTLAB, suitable for high fidelity, pilot-in-the-loop simulator. The focus is on aerodynamic modeling of AW609 tiltrotor in Airplane Mode flight regime. The framework can be extended to helicopter and conversion modes with additional considerations for rotors-airframe aerodynamic interference. It can also be adapted to different tiltrotor geometries, with some adjustments depending on their peculiarities. The model uses Blade Element Theory loads evaluation of lifting surfaces, corrected with tabulated distributed loads to tune FLIGHTLAB predictions against high-fidelity aerodynamic references. Bluff bodies are modeled using force and moment tabulated data. Verification was conducted against reference data in wind tunnel mode and against flight data in trim analysis. The proposed method allowed to match lift distribution on slender bodies, as well as lift and drag integral loads, with aerodynamic references. Trim analysis has shown satisfying accordance with experimental data for all the comparison parameters. However, rotor aerodynamic modeling is still being investigated to improve correlations in torque prediction. Additionally, installation effects, such as those related to the interaction between the wing and fuselage with the rotors, are under examination to address biases in flap motion evaluation.
