Abstract:
This paper, explores the design and sizing of a planetary gear-based electronic continuously variable transmission (ECVT) for implementation of a parallel gas-electric hybrid helicopter propulsion system. The ECVT consists of a differential planetary gear transmission (PGT) and an electric motor/generator (MG) unit. The ECVT enables power-flow between engine, motor and helicopter main rotor. The parallel arrangement enables the main rotor speed to varied continuously based on the MG speed while the engine speed can remain constant. The performance benefits enabled by the main rotor speed variation capability are offset by the added weight penalties introduced by the ECVT system. By considering factors such a as gear tooth bending and contact stress, bearing loads, required motor torque, planetary gear kinematics and pitch-line velocity constraints, this paper conducts a minimum mass design study for several PGT / ECVT arrangements. Here, three different single stage PGT/ECVT arrangements are compared along with an improved two stage ECVT. The three single stage ECVT configurations can be summarized as; I) Sun-Engine / Carrier-Motor / Ring-Out, II) Sun-Engine / Ring-Motor / Carrier-Out, and III) Carrier-Engine / Sun-Motor / Ring-Out. Of these three types, it was found that type III was significantly lighter in weight compared with types I and II since type III would have the highest relative motor speed. When sized for a 3000 Hp engine-side power input at 6000 rpm, the minimum mass design for type III was on the order of 100 lbs compared to 400 lbs and 700 lbs respectively for types I and II. Despite the seemingly obvious advantage of design type III, it's drawback is that it is effectively a speed increasing stage with respect to the engine. To address this, a two-stage ECVT with compound planetary arrangement of Type III and II was designed which achieved an overall minimum weight of 219 lbs at the 3000 Hp level while providing 1:0.351 gear reduction form engine to output. The analysis tools developed and sizing results flowing from this study will provide a baseline for evaluating performance benefits and weight penalties introduced by parallel hybrid drive-systems for rotorcraft applications.
