Abstract:
This paper explores a significant step forward, regarding the further detailed understanding of the Fenestron®. Since its patent in 1968 – for the Gazelle helicopter –, the shrouded tail rotor has been resized, inclined, modulated, etc. and has thus been continuously enhanced on different rotorcraft. Half a century after its invention, Airbus is once again exploring in more detail the magic of the Fenestron®, with the objective of optimizing it even further, for future helicopter applications. To grasp and observe properly some specific phenomena, a model (scaled to one third) capable of both unprecedented functions and modularities, was developed. The present paper will describe in detail the novel model and the related challenges and solutions. This model is capable of high rotor speed and dynamic pitch inputs, delivering power levels high enough to reach stall effects, while allowing the measurement of propulsive efficiency and to differentiate rotor vs fairing thrust. Furthermore, the model had to provide aerodynamic-shape modularity, both in the shroud, on the covers and on the tail gearbox supports. The first test campaign performed on this model allowed us to define design drivers and aerodynamic preferences. And since one idea often leads to another, another challenge is being addressed on this scaled mock-up: Reduction of the tail rotor noise level.
