Abstract:
This paper addresses the urgent need to enhance rotorcraft safety and performance by developing a prediction methodology for the onset of the Vortex Ring State (VRS), and therefore verifying the VRS avoidance diagram. The objectives of this research are to assess the correlation between predictions generated by a comprehensive flight dynamics code and the latest and most accurate VRS boundary models, validate the VRS avoidance diagram across diverse descending flight conditions, and identify specific parameters indicating the rotor's entry into the VRS. The methodology involves a detailed investigation of 8 descent manoeuvres using a comprehensive flight dynamics code coupled with an advanced free vortex wake model. Results show that the pitch and roll oscillations and thrust fluctuations experienced by helicopters during the VRS are also observed in the model response to steep descent maneuvers. The findings confirm the reliability and applicability of the VRS avoidance diagram, providing valuable insights for improving rotorcraft design and flight control systems. Furthermore, this study presents novel findings regarding the identification of the VRS onset boundary through the observation of pitch and roll rate fluctuations, which contribute to the systematic detection and prevention of the VRS.
