Abstract:
Air data measurement and calibration are fundamental components in the pursuit of accurate and reliable aerodynamic assessments. The systematic collection of essential data regarding air properties are important for evaluating aircraft performance under various conditions and configurations. The scope is to achieve a comprehensive understanding of airflow characteristics, which is fundamental for design improvements and operational strategies, contributing to safer and more efficient flight operations in a several range of scenarios. This type of data measurement is even more challenging for the AW609 Tiltrotor which combines vertical take-off technology capabilities with the fixed-wing flight efficiency. The activity starts from known pitot-static system calibration methodologies for conventional applications and shows what were the difficulties encountered in a non-conventional Tiltrotor approach. The paper goes through the presentation of the original Pitot-Static and Air Data system and all the problematics that driven to a design change. After the presentation of the new architecture and the new data collection activity, it will be discussed the optimization of the data calibration strategy, also related to some peculiarities of the Tiltrotor, and how it drives to infer the calibration curves for the Air Data Computers (ADCs).
