Abstract:
The paper describes a method for optimal design of a helicopter tail shaft that considers rotordynamic effects from long shaft assembly. The tail shaft transmits power from the main gearbox (MGB) to the tail rotor of the helicopter and operates at high speeds that may exceed 6000 rpm. While higher speeds allow for weight reduction, they also pose risks associated with supercritical operation, necessitating careful design optimization. The objective of the optimization is to maximize the first three transverse natural frequencies with the constraint of the safety parameter (avoidance of the resonance/critical zone) while minimizing the weight of the system. A Non-Dominated Sorting Genetic Algorithm (NSGA-II) is used to obtain the solution to this multiobjective optimization problem, which involves shaft design variables such as length, outer diameter, and wall thickness. In addition, the optimization framework also incorporates system related design variables, including the stiffness of tail shaft bearing supports, the location of bearings, and coupling characteristics, to comprehensively evaluate and enhance the system performance. A rotordynamics model utilizing Timoshenko beam finite elements is deployed to predict natural frequencies.
