Experimental Investigation of Rotor Blade Structural Response In Hovering and Advance Flight

Alexander D. Croke, Richard B. Green, University of Glasgow

Oliver D. Wild, Anya R. Jones, University of Maryland

May 7, 2024

https://doi.org/10.4050/F-0080-2024-1228

Abstract:
A towing tank investigation of a single rotor blade operating at hovering and high advance ratio conditions is presented. A custom blade was manufactured and instrumented with fully bridged axial strain gauges to monitor the flap bending strain at three radial locations. Measurements of rotor thrust and torque were obtained to characterise the rotor aerodynamic environment for advance ratios ranging from 0.4 to 1.00 and to identify the presence of stalled and reverse flow. Strain measurements obtained at three locations across the blade span show minima and maxima at approximately the same azimuthal location as the load data. Moreover, the strain distribution shows a growth in strain magnitude with increasing advance ratio. Spectra of strain shows a dominant 1/rev signal and for the ∅ = 25° collective, non-harmonic frequencies are observed due to aperiodic vortex shedding from the presence of stalled flow.
