Abstract:
Stretch broken carbon fiber (SBCF) offers enhanced formability as compared to continuous carbon fiber (CCF). However, robust, quantitative evaluation of forming defects remains a challenge. This study introduces a unified formability index (UFI) that integrates multiple defect types, including texture anomalies, bridging, wrinkling, thickness variation, spring-back, and resin distribution variation (RDV), into a single weighted score. Each defect is ranked on a scale of 0-5 using normalized metrics with a tunable parameter, α, allowing users to balance defect magnitude and frequency as desired. The full scoring pipeline is demonstrated for texture defects using measured data, while normalized legacy scores from previous work are used for non-texture defects to enable complete formability index computation. Case studies on three laminates illustrate how variations in α affect both texture scoring and the overall formability index and demonstrate the geometry-agnostic nature of the updated ranking and UFI systems. This framework maintains compatibility with existing evaluations while offering improved resolution, consistency, and scalability for assessing laminate quality across complex geometries.
