Abstract:
A typical helicopter drive system consists of a multi-stage gearbox with highly loaded dynamic components such as gears, shafts, and bearings, crucial for safe flight and landing. Planetary reduction stages are commonly used in the final reduction stage of rotorcraft main gearboxes due to their ability to handle high torques at high gear ratios within a compact envelope. The planet gear, a critical component in this arrangement, is subjected to significant loads on both flanks of its teeth and must meet stringent weight and assembly requirements, leading to a thin rim design with integrated bearing races. This design makes the planet gear susceptible to relevant reduction of its fatigue life. This paper explores analysis methods to evaluate the damage resistance of the planetary stage assembly, focusing on the planet gear. The study aims to assess the "growth" or "no growth" condition of the planet gear against defined flaw defects. An iterative calculation loop determines the critical length and position of a crack that may lead to full crack propagation and, in worst cases, to system jamming. Initial crack propagation simulations use NASGRO software, with stress fields derived from a non-linear FEM of the planet gear availing of detailed Transmission3D model for teeth meshing forces evaluation. Further additional analysis can involve a dedicated FE model of the crack, iteratively updating its geometry. The impact of crack propagation on the remaining components of the planetary stage assembly is also addressed, considering the unbalanced load conditions caused by stiffness loss in the planet gear. The dissertation object of this paper aims to outline a comprehensive, effective and efficient procedure to determine the maximum allowable defect size for "no growth" condition and the operational hours until failure, providing a robust approach to support the strength substantiation of the involved components.
