Abstract:
Installation effects of the Volocopter 2-X beam structures are studied by performing high-fidelity CFD simulations of a single and three-rotor configurations in hover. The studied cases are compared with simulations without airframe to investigate the installation effects. In addition, the noise emission of the configurations is simulated by using a Ffowcs Williams-Hawkings based CAA code. Scattering effects are also included by using a BEM code. The rotors are simulated at an identical RPM and are placed in their mounting position. Furthermore, an additional setup with individual rotor RPMs is simulated for the three-rotor configuration. The installation mainly affects the rotor wake, thrust and pressure fluctuations on the rotor, while the integral aerodynamic quantities remain almost unchanged. This resulted in additional oscillations in the acoustic pressure signal. Overall, the installation increases the OSPL by about 1.5 dB, but has a greater effect on the 3-20 harmonics. The simulation data were compared with the Volocopter measurements and showed good agreement. For the three-rotor configurations, the rotor-rotor interactions were found to be dominant for the aerodynamic and acoustic performance, while the installation effects only locally influenced the noise emission by 3-4dB.
