Abstract:
This study presents the design, modeling, and simulation of an Adaptive Speed Gearbox (ASG) with integrated electric variator for the UH-60A Black Hawk helicopter. The proposed drivetrain architecture enables main rotor speed variation independently of turbine speed, addressing operational demands for enhanced efficiency, noise reduction, and performance flexibility. A comprehensive aero-thermal model of the turboshaft engine, a dynamic drivetrain model, and a variable-speed control strategy were developed and validated. The control approach employs a two-degree-of-freedom structure combining nullspace-based feedforward torque allocation and modal-weighted LQR feedback for vibration suppression. A similarity theory-based scaling method was employed to design a demonstrator gearbox, facilitating experimental validation under representative conditions. The results demonstrate the feasibility of the ASG concept and establish a foundation for future experimental investigations and subsequent technology maturation towards higher TRLs.
