Abstract:
Rotorcraft experience significant vibrations due to periodic aerodynamic forces and moments on the rotor blades and wings. Rotor torque damping is a novel vibration damping method which uses small torque perturbations from the main electric motor to reduce vibrations. The large inertial and aerodynamic rotor loading and relatively high frequency torque perturbations mean that the rotor speed changes are small, so the rotor thrust and flight control performance are not significantly affected. This paper investigates the application of electric motor torque control for damping structural vibrations of an aircraft. The structural dynamics of the aircraft are represented using a finite element model of a quad tiltrotor eVTOL. Using collocated angular rate feedback on all four rotors provides more than 10% damping in controllable modes. The RMS value of flap-wise angular rate can be reduced by 91% with less than 1.2 RPM rotor speed change in response to a 20% vertical step gust in airplane mode. For N/rev disturbance cancellation, an optimal controller is designed assuming known disturbance location and frequency for active vibration control (AVC). The transfer matrix of a single cantilevered wing is calculated and used to feed forward harmonic rotor torques. The wing undergoes aerodynamic disruptions at N/rev and the harmonic controller reduces N/rev shear force and bending moment at the root by 20% and 58% with less than 1 RPM rotor speed change, respectively.
