Abstract:
Updates to the military rotorcraft handling qualities specification are currently being considered that address the high-speed flight regime envisioned for the Future Vertical Lift platform of the US Army. A team that features industry and academia have developed and evaluated a set of Mission Task Elements (MTEs) that have been defined to address VTOL high-speed handling qualities. Following the mission-oriented approach upon which ADS-33E-PRF is based, the MTEs were designed to meet different levels of precision and aggressiveness. The attitude capture and hold MTEs that are the subject of this paper were defined to be precision, non-aggressive tasks that build upon fixed wing analogs. The MTE objectives, descriptions, and performance criteria were assessed and refined via several checkout piloted simulation sessions. Formal evaluations were then conducted by Army test pilots at four simulator facilities, each featuring a unique high-speed platform including a generic winged compound helicopter, two tiltrotor configurations, and a compound helicopter with coaxial rotors. To aid in the MTE evaluation process, baseline VTOL configurations were varied to achieve different handling qualities levels. Quantitative measures based on task performance and qualitative measures based on pilot ratings, comments and debrief questionnaires were used to assess MTE effectiveness. The piloted simulation results demonstrated that the attitude capture and hold MTEs provided an effective means to discern precision, non-aggressive handling qualities in high speed flight.
